| Model | HYS5070GQXE6 | |
| Gross Weight | 7360(kg) | |
| Rated Load | 2630 (Kg) | |
| Curb Weight | 4600(kg) | |
| Dimensions | 5387,5637,5995×2200×2600(mm) | |
| Approaching/Departuring Angle | 27.7/15(°) | |
| Front/Rear Overhang | 1055/1632(mm) | |
| Number of Axles | 2 | |
| Wheelbase | 2700,2950,3308(mm) | |
| Axle Load | 2640/4720(kg) | |
| Max Speed | 110(km/h) | |
| Chassis type | EQ1075SJ3CDF | |
| Number of Tires | 6 | |
| Number of Leaf Spring | 6/6+5,3/3+3,5/4+3,6/4+3,6/5+2,6/3+3,3/6+5,3/3+2,2/2 | |
| Tire | 7.00R16,7.00R16LT,7.00R16LT 14PR | |
| Front Wheel Track | 1525,1519,1503,1613(mm) | |
| Rear Wheel Track | 1498,1516,1586,1670,1650(mm) | |
| Chassis Discharge Standard | GB17691-2018 National VI Emission Standards | |
| Fuel Type | Diesel | |
| Engine Model | CY4BK461, CA4DB1-11E6, CY4BK161, D20TCIF1, Q28-130E60, H20-120E60, CA4DB1-13E6, YCY24140-60, D20TCIF11, Q23-115E60, ZD30D16-6N, M9T-600 | |
| Engine Displacement | 1999 - 3856 (ml) | |
| Engine Max Power | 81 - 120(kw) | |
