| Basic Information | |||
| Usage | Delivery Vehicle | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 11790mm | ||
| Width | 2500mm | ||
| Height | 3505mm | ||
| Curb Weight | 13980kg | ||
| Gross Weight | 31000kg | ||
| Seats | 2,3 | ||
| Max Speed | 89km/h | ||
| Chassis | |||
| Chassis Model | CA1310P63K1L6T10E5 | ||
| Front/Rear Overhang | 1400/2840mm | ||
| Number of Leaf Springs | 3/3/12/10+9,3/3/-/10+9,3/3/5+-/10+9 | ||
| Number of Axles | 4 | ||
| Wheelbase | 1950+4250+1350mm | ||
| Axle Load | 6500/6500/18000(two axles)kg | ||
| Front Wheel Track | 1950/1950mm | ||
| Rear Wheel Track | 1914/1869,1914/1878mm | ||
| Approaching/Departuring Angle | 21/10° | ||
| Tire | |||
| Number of Tires | 10 | ||
| Tire | 11.00R20,295/80R22.5,12R22.5 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| CA6DK1-28E5 | China FAW Corporation Group | 209kW | 7146ml |
