| Basic Information | |||
| Usage | Engineering Vehicle | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2018 national Ⅵ emission standards | ||
| Length | 10200mm | ||
| Width | 2550mm | ||
| Height | 3990mm | ||
| Curb Weight | 13430kg | ||
| Gross Weight | 31000kg | ||
| Seats | 2 | ||
| Max Speed | 85km/h | ||
| Chassis | |||
| Chassis Model | QCC5313GJBD666-E1 | ||
| Front/Rear Overhang | 1515/2485mm | ||
| Number of Leaf Springs | 3/3/4,3/3/5,4/4/5,9/9/11,9/9/12,10/10/12,12/12/13 | ||
| Number of Axles | 4 | ||
| Wheelbase | 2100+2750+1350mm | ||
| Axle Load | 6500/6500/18000(two axles)kg | ||
| Front Wheel Track | 2040/2040,2080/2080,2115/2115mm | ||
| Rear Wheel Track | 1860/1860,1890/1890mm | ||
| Approaching/Departuring Angle | 23/15° | ||
| Tire | |||
| Number of Tires | 12 | ||
| Tire | 11.00R20 18PR,12.00R20 18PR,12R22.5 18PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| YCK08350-60 | Guangxi Yuchai Machinery Co., Ltd. | 257kW | 7698ml |
| WP8.350E61 | Weichai Power Co., Ltd. | 257kW | 7800ml |
