Dongfeng 8*4 27cbm huge chemical tanker+Dongfeng Cummins Power

Dongfeng 8*4 27cbm huge chemical tanker+Dongfeng Cummins Power
Dongfeng 8*4 27cbm huge chemical tanker+Dongfeng Cummins Power Dongfeng 8*4 27cbm huge chemical tanker+Dongfeng Cummins Power
Views:0
Basic Information
Usage Aluminum Alloy Oil Tanker

Model: CLW5312GHYD

Overall Dimension: 11990*2500*3690,3300mm (L*W*H)

Curb Weight: 14170kg

Payload Weight: 16635kg, 16700kg

Gross Weight: 31000kg

Driving Type: 8×4

Max Speed: 90

Wheelbase: 1950+4250+1300

Fuel Type: diesel

Tire: 11.00R20

Chassis Model: DFL1311A4

Vehicle Name: Dongfeng KL Chemical Liquid Transport Truck

Tank Dimension: 9100*2400*1650mm

Approach / Departure angle: 20/10°

Front /rear suspension(mm): 1460/3030,1460/2980

Engine Type: DFL1311A4

Displacement(ml)/Power(kw): 8900/231

Engine Manufacturer: Dongfeng Cummins engine

Tread (front/rear): 1940/1940/1860/1860

Front Axle: 5T(double axle)

Rear Axle: 10T(double axle)

Steering Gear: Duel-armed steering wheel,recirculating ball steering

Transmission: Shangxi9-forward gear 9JS119T-B transmission

Clutch: Uniwafer,dry diaphragm spring clutch

Braking System: Brake fluid system, drum brake

Cabin: Flat-head,one and half row with added long cab,whole metal-enclosed

Number of spring axle(front/rear): 8/8/10

Air Condition: Choose to fix

Tank Material: Carbon steel, stainless steel,plastic,liner steel,glass steel etc.

Tank Type: Square-round,round,ellips

Fuel pump(optional): Self-priming pump,gear pump,chemical pump,stainless steel pump

Fuel meter(optional): Single/double counting,tax controlling oilier

Tank function: Divided Separately to several unattached small tanks to fill different fuels,meanwhile reduce pressure from tanker inner when braking, it could be adjusted chemical tanker
