Jiangling Isuzu 9t Cleaning Sweeper

Jiangling Isuzu 9t Cleaning Sweeper
Jiangling Isuzu 9t Cleaning Sweeper Jiangling Isuzu 9t Cleaning Sweeper Jiangling Isuzu 9t Cleaning Sweeper Jiangling Isuzu 9t Cleaning Sweeper
Basic Information
Usage Street Sprinkler
Model JDF5100TXSQ5
Gross Weight 10000(kg)
Rated Load 2025 (Kg)
Curb Weight 7780(kg)
Dimensions 7610×2200×2640(mm)
Approaching/Departuring Angle 17/15(°)
Front/Rear Overhang 1110/2025(mm)
Number of Axles 2
Wheelbase 4475(mm)
Axle Load 3350/6650(kg)
Max Speed 110(km/h)
Chassis type QL1100A8MAY
Number of Tires 6
Number of Leaf Spring 8/10+6
Tire 235/75R17.5 14PR,8.25R20 14PR
Front Wheel Track 1680(mm)
Rear Wheel Track 1650(mm)
Chassis Discharge Standard GB17691-2005 National V Emission Standards, GB3847-2005
Fuel Type Diesel
Engine Model 4HK1-TC51, 4HK1-TC50
Engine Displacement 5193 (ml)
Engine Max Power 141 - 151(kw)
