| Basic Information | |||
| Usage | Medical Vehicle | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 7530mm | ||
| Width | 2305mm | ||
| Height | 2820,2970,3060,3210mm | ||
| Curb Weight | 6605kg | ||
| Gross Weight | 6800,6700,6600,6500kg | ||
| Seats | 3 | ||
| Max Speed | 120km/h | ||
| Chassis | |||
| Chassis Model | NJ1075ELC | ||
| Front/Rear Overhang | 998/2182mm | ||
| Number of Leaf Springs | -/7,-/3 | ||
| Number of Axles | 2 | ||
| Wheelbase | 4350mm | ||
| Axle Load | 2050/4750,2000/4700,1950/4650,1900/4600kg | ||
| Front Wheel Track | 1724mm | ||
| Rear Wheel Track | 1663mm | ||
| Approaching/Departuring Angle | 24.5/12.2° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 225/75R16LT | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| F1CE34818 | NAVECO Ltd. | 107kW | 2998ml |
