| Basic Information | |||
| Usage | Others | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅳ emission standards, GB3847-2005 | ||
| Length | 9895mm | ||
| Width | 2480mm | ||
| Height | 3435,3600mm | ||
| Curb Weight | 12000kg | ||
| Gross Weight | 13700kg | ||
| Seats | 10-21 | ||
| Max Speed | 115km/h | ||
| Chassis | |||
| Chassis Model | XMQ6960R2 | ||
| Front/Rear Overhang | 1975/2920mm | ||
| Number of Leaf Springs | 7/10,3/3,-/- | ||
| Number of Axles | 2 | ||
| Wheelbase | 5000mm | ||
| Axle Load | 4250/9450kg | ||
| Front Wheel Track | 1920,2054,2054mm | ||
| Rear Wheel Track | 1800,1840,1850mm | ||
| Approaching/Departuring Angle | 10/8° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 10R22.5 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| ISBE4+225 | Cummins Inc. | 165kW | 6700ml |
| YC6J245-42 | Guangxi Yuchai Machinery Co., Ltd. | 180kW | 6500ml |
