| Basic Information | |||
| Usage | Engineering Vehicle | ||
| Fuel Type | Natural gas | ||
| Emission Standard | GB17691-2018 national Ⅵ emission standards | ||
| Length | 10350,9950mm | ||
| Width | 2550mm | ||
| Height | 3990mm | ||
| Curb Weight | 13780kg | ||
| Gross Weight | 31000kg | ||
| Seats | 2 | ||
| Max Speed | 80km/h | ||
| Chassis | |||
| Chassis Model | CQ3317HL6T | ||
| Front/Rear Overhang | 1435/2515,1435/2115mm | ||
| Number of Leaf Springs | 3/3/6,8/8/12,9/9/12,10/10/12,3/3/4 | ||
| Number of Axles | 4 | ||
| Wheelbase | 2000+2800+1400,2000+3000+1400,2000+3150+1400,2000+3300+1400,2000+3600+1400mm | ||
| Axle Load | 6500/6500/18000(two axles)kg | ||
| Front Wheel Track | 2020/2020,2040/2040,2060/2060mm | ||
| Rear Wheel Track | 1858/1858mm | ||
| Approaching/Departuring Angle | 16/14° | ||
| Tire | |||
| Number of Tires | 12 | ||
| Tire | 12R22.5 18PR,315/80R22.5 18PR,11.00R20 18PR,12.00R20 18PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| SC10ET320Q6 | Shanghai Diesel Engine Co., Ltd. | 235kW | 10420ml |
| SC10ET340Q6 | Shanghai Diesel Engine Co., Ltd. | 250kW | 10420ml |
| SC10ET360Q6 | Shanghai Diesel Engine Co., Ltd. | 265kW | 10420ml |
| SC10ET380Q6 | Shanghai Diesel Engine Co., Ltd. | 280kW | 10420ml |
