| Model | CLW5162GPSHDL |
| Gross Weight | 16000(kg) |
| Volume | 10.5(cubic meter) |
| Rated Load | 10000,9935(Kg) |
| Curb Weight | 5,870(kg) |
| Dimensions | 7700,8300×2480,2500×3350,3600(mm) |
| Approaching/Departuring Angle | 17/24,17/21(°) |
| Front/Rear Overhang | 1250/2500,1250/2550,1450/2300,1450/2350(mm) |
| Number of Axles | 2 |
| Wheelbase | 3950,4200,4500,4700,5100,5600(mm) |
| Axle Load | 5600/10400(kg) |
| Max Speed | 88(km/h) |
| Chassis type | EQ1160GL6DJ |
| Number of Tires | 6 |
| Number of Leaf Spring | 9/11+8,9/10+8 |
| Tire | 9.00R20 16PR |
| Front Wheel Track | 1820,1920,1950(mm) |
| Rear Wheel Track | 1800,1860(mm) |
| Chassis Discharge Standard | GB3847-2005,GB17691-2018 National Ⅵ Emission Standards |
| Fuel Type | Diesel |
| Engine Model | YCY30165-60, YCS04200-68, D25TCIF1, D30TCIF1, YCS04160-68, YCS04180-68 |
| Engine Displacement | 2,499 – 4,156(ml) |
| Engine Max Power | 110 -147(kw) |
