| Basic Information | |||
| Usage | Tree Sprinkling Tanker | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB3847-2005,GB17691-2018 National Ⅵ Emission Standards | ||
| Length | 7770,7660mm | ||
| Width | 2550mm | ||
| Height | 3200mm | ||
| Curb Weight | 6845kg | ||
| Gross Weight | 18000kg | ||
| Max Speed | 105km/h | ||
| Chassis | |||
| Chassis Model | EQ1185LJ9CDE | ||
| Front/Rear Overhang | 1260/2560,1260/2450mm | ||
| Number of Leaf Springs | 8/10+7,8/- | ||
| Number of Axles | 2 | ||
| Wheelbase | 3600,3950,4500,4700,5000,5300,5600mm | ||
| Axle Load | 6500/11500kg | ||
| Front Wheel Track | 1862,1933,1949mm | ||
| Rear Wheel Track | 1806,1865mm | ||
| Approaching/Departuring Angle | 18/12° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 295/80R22.5 18PR,10.00R20 18PR,275/80R22.5 18PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| B6.2NS6B210 | 121 - 169kW | 2970 - 6200ml | |
| D4.5NS6B220 | |||
| D4.0NS6B195 | |||
| YCS04200-68 | |||
| CY4SK761 | |||
| B6.2NS6B230 | |||
| YCY30165-60 | |||
