| Model | CLW5250GSS6KL |
| Gross Weight | 25000(kg) |
| Volume | 14.68(cubic meter) |
| Rated Load | 14050,13985(Kg) |
| Curb Weight | 10820(kg) |
| Dimensions | 10250×2500×3220(mm) |
| Approaching/Departuring Angle | 16/18(°) |
| Front/Rear Overhang | 1450/3125,1450/3150,1450/2825(mm) |
| Number of Axles | 3 |
| Wheelbase | 3875+1400,3900+1350,4275+1400,4300+1350,4575+1400,4600+1350,4975+1400,5000+1350,5375+1400,5400+1350,5775+1400,5800+1350(mm) |
| Axle Load | 7000/18000 (kg) (two axles) |
| Max Speed | 110(km/h) |
| Chassis type | ZZ5256XXYN504GF1 |
| Number of Tires | 10 |
| Number of Leaf Spring | 3/4,3/5,3/10,11/10,11/12,3/-/- |
| Tire | 12.00R20 16PR,11.00R20 18PR,12R22.5 18PR,295/80R22.5 18PR,315/80R22.5 18PR/315/80R22.5 16PR |
| Front Wheel Track | 1998,2035(mm) |
| Rear Wheel Track | 1850/1850(mm) |
| Chassis Discharge Standard | GB17691-2018 National Ⅵ Emission Standards |
| Fuel Type | Diesel |
| Engine Model | MC07.27-60, MC07.31-60, MC07.34-60, WP8.350E61, WP6H270E61, MC09.35-60, MC09.38-60, MC07.33-60, MC07.25-60, MC07H.29-60, MC07H.33-60, MC07H.35-60, WP7.270E61, WP7.300E61, WP8.320E61 |
| Engine Displacement | 6220 - 8765(ml) |
| Engine Max Power | 188 - 279(kw) |
