| Model | CLW5162GSS6 |
| Gross Weight | 16200(kg) |
| Volume | 9.71(cubic meter) |
| Rated Load | 9320,9255(Kg) |
| Curb Weight | 6750(kg) |
| Dimensions | 7660×2520×3200(mm) |
| Approaching/Departuring Angle | 18/12(°) |
| Front/Rear Overhang | 1260/2450(mm) |
| Number of Axles | 2 |
| Wheelbase | 3950,4500,4700,5000,5300,5600 (mm) |
| Axle Load | 5600/10600 (kg) |
| Max Speed | 105(km/h) |
| Chassis type | EQ1165LJ9CDE |
| Number of Tires | 6 |
| Number of Leaf Spring | 8/10+7 |
| Tire | 9.00R20 16PR,10.00R20 18PR,295/80R22.5 18PR,275/80R22.5 18PR |
| Front Wheel Track | 1862,1933,1949(mm) |
| Rear Wheel Track | 1806,1865(mm) |
| Chassis Discharge Standard | GB3847-2005, GB17691-2018 National VI Emission Standards |
| Fuel Type | Diesel |
| Engine Model | B6.2NS6B210, D4.5NS6B220, D4.0NS6B195, YCS04200-68, CY4SK761, B6.2NS6B230, YCY30165-60 |
| Engine Displacement | 2970 - 6200(ml) |
| Engine Max Power | 121 - 169(kw) |
