| Model | CLW5081GSSB5 |
| Gross Weight | 8280(kg) |
| Volume | 4.59(cubic meter) |
| Rated Load | 4450,4385(Kg) |
| Curb Weight | 3700(kg) |
| Dimensions | 6170×2120×2350 (mm) |
| Approaching/Departuring Angle | 22/15(°) |
| Front/Rear Overhang | 1120/1690(mm) |
| Number of Axles | 2 |
| Wheelbase | 3360 (mm) |
| Axle Load | 3000/5280 (kg) |
| Max Speed | 110 (km/h) |
| Chassis type | BJ1089VEJEA-F3 |
| Number of Tires | 6 |
| Number of Leaf Spring | 3+1/6+7,9/11+7,3/7+6,3/8+6,3/4+2,3/5+2 |
| Tire | 7.50R16 |
| Front Wheel Track | 1530,1710,1730,1665,1590(mm) |
| Rear Wheel Track | 1485,1590,1630,1615,1800 (mm) |
| Chassis Discharge Standard | GB17691-2005 National V Emission Standards, GB3847-2005 |
| Fuel Type | Diesel |
| Engine Model | ISF3.8s5141, ISF2.8s5129T, ISF2.8s5R117, 4J28TC3, ISF3.8s5154, 4J28TC5, ISF2.8s5F130, CY4BK151, WP3.7Q130E50, 4B2-115C50 |
| Engine Displacement | 2545 - 3856 (ml) |
| Engine Max Power | 81 - 115(kw) |
