| Model | CLW5161GSST5 |
| Gross Weight | 16000(kg) |
| Volume | 9.4(cubic meter) |
| Rated Load | 9030,8965(Kg) |
| Curb Weight | 6840(kg) |
| Dimensions | 8600,8400,8200,7850,7650,7900,7700,7500,7150,6950×2480×3200 (mm) |
| Approaching/Departuring Angle | 24/11,24/13(°) |
| Front/Rear Overhang | 1450/2450,1250/2450,1450/1750,1250/1750(mm) |
| Number of Axles | 2 |
| Wheelbase | 3650,3800,3950,4200,4500,4700,5100,5600,5200(mm) |
| Axle Load | 5600/10400(kg) |
| Max Speed | 90(km/h) |
| Chassis type | EQ1168GLJ4 |
| Number of Tires | 6 |
| Number of Leaf Spring | 9/11+8,8/10+8,8/11+8,9/10+8,3/4+3 |
| Tire | 10.00-20 16PR,10.00R20 16PR,9.00R20 16PR,10R22.5 16PR,275/80R22.5 16PR |
| Front Wheel Track | 1910,1760,1940,1960,1810(mm) |
| Rear Wheel Track | 1860,1690,1750,1800(mm) |
| Chassis Discharge Standard | GB17691-2005 National V Emission Standards, GB3847-2005 |
| Fuel Type | Diesel |
| Engine Model | YC6J180-50, YC4EG160-50, ISD185 50, CA4DLD-15E5, ISB170 50, ISB190 50, YC4E160-56, YC6JA180-50, CY4SK151, YCD4J4S-150, ISD160 50, ISD180 50, YCD4D4S-140, YC4EG185-50, YC4FA130-50, YN38CRE1 |
| Engine Displacement | 2982 - 6870(ml) |
| Engine Max Power | 95 - 140 (kw) |
