| Model | CLW5070TSLJ6 |
| Gross Weight | 7300(kg) |
| Rated Load | 2210(Kg) |
| Curb Weight | 4960(kg) |
| Dimensions | 6190×1990×2590(mm) |
| Approaching/Departuring Angle | 20/13(°) |
| Front/Rear Overhang | 1075/1755(mm) |
| Number of Axles | 2 |
| Wheelbase | 3360(mm) |
| Axle Load | 2600/4700(kg) |
| Max Speed | 80(km/h) |
| Chassis type | JX1071TG26 |
| Number of Tires | 6 |
| Number of Leaf Spring | 8/8+7,5/4+3,5/3+4,5/4+4,5/4+5,5/6+5,5/5+5,8/6+5,8/5+5,8/8+3,8/4+4,8/4+5,8/5+4,8/4+3,8/3+3,8/3+4,9/6+ |
| Tire | 7.00R16LT 14PR |
| Front Wheel Track | 1575,1466 (mm) |
| Rear Wheel Track | 1508,1440(mm) |
| Chassis Discharge Standard | GB3847-2005, GB17691-2018 National VI Emission Standards |
| Fuel Type | Diesel |
| Engine Model | JX4D30D6H |
| Engine Displacement | 2892(ml) |
| Engine Max Power | 85(kw) |
