| Model | CLW5080TSL6CD |
| Gross Weight | 8210(kg) |
| Rated Load | 2185,1605(Kg) |
| Curb Weight | 5830,6410(kg) |
| Dimensions | 7000,7100×2200×2700(mm) |
| Approaching/Departuring Angle | 20/10,20/9(°) |
| Front/Rear Overhang | 1155/2030,1155/2130(mm) |
| Number of Axles | 2 |
| Wheelbase | 3815(mm) |
| Axle Load | 2940/5270(kg) |
| Max Speed | 115 (km/h) |
| Chassis type | JX1083TK26 |
| Number of Tires | 6 |
| Number of Leaf Spring | 8/8+8,8/3+2,8/4+2,8/5+4,4/8+8,4/3+2,4/4+2,4/5+4 |
| Tire | 7.50R16LT 14PR |
| Front Wheel Track | 1680 (mm) |
| Rear Wheel Track | 1640,1800(mm) |
| Chassis Discharge Standard | GB3847-2005, GB17691-2018 National VI Emission Standards |
| Fuel Type | Diesel |
| Engine Model | JX4D306H |
| Engine Displacement | 2892(ml) |
| Engine Max Power | 112(kw) |
