| Model | CLW5180TXSCD6 |
| Gross Weight | 18000(kg) |
| Rated Load | 5370,5305(Kg) |
| Curb Weight | 12500(kg) |
| Dimensions | 9100,8700,8200,8000,7900,7650×2500×3000(mm) |
| Approaching/Departuring Angle | 17/25,17/26,17/26,17/26,17/27,17/29,17/28(°) |
| Front/Rear Overhang | 1400/2100,1475/2025,1400/2100,1400/2100,1400/2100,1400/2300,1400/2550,1400/2450(mm) |
| Number of Axles | 2 |
| Wheelbase | 3800,3950,4200,4500,4700,5200,5600,5100,7150(mm) |
| Axle Load | 6500/11500(kg) |
| Max Speed | 89(km/h) |
| Chassis type | DFV1182GP6NJ |
| Number of Tires | 6 |
| Number of Leaf Spring | 8/10+7,8/10+8 |
| Tire | 10.00R20 16PR,10.00R20 18PR,11.00R20 16PR,11.00R20 18PR,295/80R22.5 18PR |
| Front Wheel Track | 1810,1880,1900,1940,1965(mm) |
| Rear Wheel Track | 1800,1820,1860(mm) |
| Chassis Discharge Standard | GB17691-2018 National VI Emission Standards |
| Fuel Type | NG |
| Engine Model | YCA07260N-60, YCA07245N-60, YCA07220N-60, YCA07190N-60 |
| Engine Displacement | 6871(ml) |
| Engine Max Power | 140 - 191(kw) |
