| Model | JDF5160TXSZ5 |
| Gross Weight | 16000(kg) |
| Rated Load | 3480,3415,4180,4115(Kg) |
| Curb Weight | 12390,11690(kg) |
| Dimensions | 8800,8500,8300×2500×3250(mm) |
| Approaching/Departuring Angle | 19/13(°) |
| Front/Rear Overhang | 1430/2370(mm) |
| Number of Axles | 2 |
| Wheelbase | 4500,4700,5000(mm) |
| Axle Load | 6000/10000(kg) |
| Max Speed | 101(km/h) |
| Chassis type | ZZ1167K501GE1 |
| Number of Tires | 6 |
| Number of Leaf Spring | 11/9+8,3/9+8,3/3+2 |
| Tire | 275/80R22.5,10.00R20,10.00-20 |
| Front Wheel Track | 1930,1960,2045(mm) |
| Rear Wheel Track | 1800,1860,1860 (mm) |
| Chassis Discharge Standard | GB17691-2005 National V Emission Standards, GB3847-2005 |
| Fuel Type | Diesel |
| Engine Model | MC05.16-50, MC05.18-50, MC05.21-50, MC07.21-50, MC07.24-50 |
| Engine Displacement | 4580 - 6870 (ml) |
| Engine Max Power | 118 - 176(kw) |
