| Model | HYS5091TXSH5 |
| Gross Weight | 9495(kg) |
| Rated Load | 2650(Kg) |
| Curb Weight | 6650(kg) |
| Dimensions | 7100×2130×2700(mm) |
| Approaching/Departuring Angle | 24/12(°) |
| Front/Rear Overhang | 1085/2200(mm) |
| Number of Axles | 2 |
| Wheelbase | 3815,3365(mm) |
| Axle Load | 3095/6400(kg) |
| Max Speed | 100(km/h) |
| Chassis type | HFC1091P91K1C5ZV |
| Number of Tires | 6 |
| Number of Leaf Spring | 8/6+6,9/6+6,9/12+6,8/12+6 |
| Tire | 8.25R16LT 16PR,8.25-16LT 16PR |
| Front Wheel Track | 1685(mm) |
| Rear Wheel Track | 1600(mm) |
| Chassis Discharge Standard | GB17691-2005 National V Emission Standards, GB3847-2005 |
| Fuel Type | Diesel |
| Engine Model | WP3Q130E50 | D30TCIE1 |
| Engine Displacement | 2970 - 2977 (ml) |
| Engine Max Power | 96 - 115(kw) |
