| Model | HYS5250TXSE5 |
| Gross Weight | 25000(kg) |
| Rated Load | 7145,8255,7210,8320(Kg) |
| Curb Weight | 17660,16550(kg) |
| Dimensions | 10600,10800,10060×2500×3350(mm) |
| Approaching/Departuring Angle | 17/15(°) |
| Front/Rear Overhang | 1480/2420,1480/2420,1480/2880,1480/2270(mm) |
| Number of Axles | 3 |
| Wheelbase | 4350+1350,5350+1350,5700+1350,3800+1350,4600+1350(mm) |
| Axle Load | 7000/18000(kg)(Two axles) |
| Max Speed | 90(km/h) |
| Chassis type | DFL1250A13 |
| Number of Tires | 10 |
| Number of Leaf Spring | 8/9,8/10,9/10 |
| Tire | 11.00-20 18PR,11.00R20 18PR,295/80R22.5 18PR,12.00R20 16PR |
| Front Wheel Track | 2040,1965,2020(mm) |
| Rear Wheel Track | 1860/1860,1880/1880(mm) |
| Chassis Discharge Standard | GB3847-2005, GB17691-2005 National V Emission Standards |
| Fuel Type | Diesel |
| Engine Model | ISD245 50, ISD270 50, DDi75S350-50, DDi75S245-50, DDi75S292-50, YC6JA240-50 |
| Engine Displacement | 6700 - 7530 (ml) |
| Engine Max Power | 180 - 257(kw) |
