| Model | CLW5070GXE4 |
| Gross Weight | 7320 (kg) |
| Volume | 4.0 (cubic meter) |
| Rated Load | 3500 (Kg) |
| Curb Weight | 3625 (kg) |
| Dimensions | 5995×1960×2400 (mm) |
| Approaching/Departuring Angle | 22/16(°) |
| Front/Rear Overhang | 1053/1592(mm) |
| Number of Axles | 2 |
| Wheelbase | 3350,3308 (mm) |
| Axle Load | 2930/4390 (kg) |
| Max Speed | 90 (km/h) |
| Chassis type | DFA1070SJ41D6 |
| Number of Tires | 6 |
| Number of Leaf Spring | 6/5+5 |
| Tire | 7.00-16 14PR,7.00R16 14PR,7.50-16 14PR,7.50R16 14PR |
| Front Wheel Track | 1598,1562,1608 (mm) |
| Rear Wheel Track | 1458,1586,1486 (mm) |
| Chassis Discharge Standard | GB3847-2005, GB17691-2005 National IV Emission Standards |
| Fuel Type | Diesel |
| Engine Model | ZD30D13-4N, D28D11-4DA |
| Engine Displacement | 2771 - 2953 (ml) |
| Engine Max Power | 85 - 96 (kw) |
