| Model | CLW5160GXEB4 |
| Gross Weight | 16000 (kg) |
| Volume | 10.08(cubic meter) |
| Rated Load | 8650 (Kg) |
| Curb Weight | 7350 (kg) |
| Dimensions | 8050×2480×3150 (mm) |
| Approaching/Departuring Angle | 22/6(°) |
| Front/Rear Overhang | 1365/2185(mm) |
| Number of Axles | 2 |
| Wheelbase | 3800,4500,5200(mm) |
| Axle Load | 6000/10000 (kg) |
| Max Speed | 90 (km/h) |
| Chassis type | BJ5163ELFHD |
| Number of Tires | 6 |
| Number of Leaf Spring | 10/10+8 |
| Tire | 9.00R20 16PR,10.00-20 18PR,10.00R20 18PR |
| Front Wheel Track | 1883(mm) |
| Rear Wheel Track | 1847 (mm) |
| Chassis Discharge Standard | GB17691-2005 |
| Fuel Type | |
| Engine Model | ISDe210 40, YC6J200-42, IE6D210-e4ES, ISDe185 40, ISB190 40, ISB210 40, IE6D190-e4ES, ISB170 40 |
| Engine Displacement | 5900 - 6700 (ml) |
| Engine Max Power | 125 - 155 (kw) |
