| Basic Information | |||
| Usage | Recreational Vehicle | ||
| Fuel Type | Gasoline | ||
| Emission Standard | GB14762-2008 national IV emission standards, GB18285-2005,GB11340-2005,GB14763-2005 | ||
| Length | 7220mm | ||
| Width | 2375mm | ||
| Height | 3335mm | ||
| Curb Weight | 3850kg | ||
| Gross Weight | 5000kg | ||
| Seats | 2,6 | ||
| Max Speed | 100km/h | ||
| Chassis | |||
| Chassis Model | Sprinter 524 second class Daimler AG | ||
| Front/Rear Overhang | 1021/1874mm | ||
| Number of Leaf Springs | -/3 | ||
| Number of Axles | 2 | ||
| Wheelbase | 4325mm | ||
| Axle Load | 1820/3180kg | ||
| Front Wheel Track | 1708mm | ||
| Rear Wheel Track | 1521mm | ||
| Approaching/Departuring Angle | 19/17° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 205/75R16C | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| 272979 | Daimler AG | ||
