| Basic Information | |||
| Usage | Vehicle for Special Work | ||
| Fuel Type | Gasoline | ||
| Emission Standard | GB14762-2008 national Ⅳ emission standards, GB18285-2005,GB11340-2005,GB14763-2005 | ||
| Length | 7005mm | ||
| Width | 2040mm | ||
| Height | 2945mm | ||
| Curb Weight | 4270kg | ||
| Gross Weight | 5300kg | ||
| Seats | 9 | ||
| Max Speed | 110km/h | ||
| Chassis | |||
| Chassis Model | SCT6704TRB53L Sichuan FAW Toyota Motor | ||
| Front/Rear Overhang | 1165/1905mm | ||
| Number of Leaf Springs | -/2 | ||
| Number of Axles | 2 | ||
| Wheelbase | 3935mm | ||
| Axle Load | 2100/3200kg | ||
| Front Wheel Track | 1690mm | ||
| Rear Wheel Track | 1490mm | ||
| Approaching/Departuring Angle | 16.8/12.7° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 7.00R16 LT 12PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| 3TR | Toyota Motor Corporation | 113kW | 2694ml |
