| Basic Information | |||
| Usage | Vehicle for Special Work | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 8880mm | ||
| Width | 2490mm | ||
| Height | 3570mm | ||
| Curb Weight | 13500kg | ||
| Gross Weight | 13630kg | ||
| Seats | 2 | ||
| Max Speed | 102km/h | ||
| Chassis | |||
| Chassis Model | ZZ1167M4617E1 | ||
| Front/Rear Overhang | 1500/2780mm | ||
| Number of Leaf Springs | 10/9+6,5/9+6 | ||
| Number of Axles | 2 | ||
| Wheelbase | 4600,5600mm | ||
| Axle Load | 5170/8460kg | ||
| Front Wheel Track | 2022,2041mm | ||
| Rear Wheel Track | 1830mm | ||
| Approaching/Departuring Angle | 14/11° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 315/80R22.5 18PR,12.00R20 18PR,11.00R20 18PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| D10.28-50 | China National Heavy Duty Truck Group Co., Ltd. | 206kW | 9726ml |
| D10.31-50 | China National Heavy Duty Truck Group Co., Ltd. | 228kW | 9726ml |
| D10.34-50 | China National Heavy Duty Truck Group Co., Ltd. | 249kW | 9726ml |
