| Basic Information | |||
| Usage | Vehicle for Special Work | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅳ emission standards, GB3847-2005 | ||
| Length | 9515mm | ||
| Width | 2540mm | ||
| Height | 3812mm | ||
| Curb Weight | 13650kg | ||
| Gross Weight | 13780kg | ||
| Seats | 2 | ||
| Max Speed | 80km/h | ||
| Chassis | |||
| Chassis Model | ZZ2167M5227D1 | ||
| Front/Rear Overhang | 1578/2737mm | ||
| Number of Leaf Springs | 9/9+6 | ||
| Number of Axles | 2 | ||
| Wheelbase | 3800,4300,4600,5200mm | ||
| Axle Load | 5910/7870kg | ||
| Front Wheel Track | 2022,2041,2087mm | ||
| Rear Wheel Track | 1830,2087mm | ||
| Approaching/Departuring Angle | 16/12.2° | ||
| Tire | |||
| Number of Tires | 6,4 | ||
| Tire | 11.00-20,11.00R20,12.00-20 16PR,12.00R20 16PR,14.00-20,14.00R20 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| D10.28-40 | China National Heavy Duty Truck Group Co., Ltd. | 206kW | 9726ml |
| D10.31-40 | China National Heavy Duty Truck Group Co., Ltd. | 228kW | 9726ml |
