| Basic Information | |||
| Usage | Police Van | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅳ emission standards, GB3847-2005 | ||
| Length | 5418,5568mm | ||
| Width | 1974mm | ||
| Height | 2370mm | ||
| Curb Weight | 2280kg | ||
| Gross Weight | 3510kg | ||
| Seats | 3 | ||
| Max Speed | 105km/h | ||
| Chassis | |||
| Chassis Model | JX6547D-M, Jiangling Motors Group Co., Ltd. | ||
| Front/Rear Overhang | 945/903,945/1053mm | ||
| Number of Leaf Springs | -/3 | ||
| Number of Axles | 2 | ||
| Wheelbase | 3570mm | ||
| Axle Load | 1670/1840kg | ||
| Front Wheel Track | 1692mm | ||
| Rear Wheel Track | 1700mm | ||
| Approaching/Departuring Angle | 19/18° | ||
| Tire | |||
| Number of Tires | 4 | ||
| Tire | 225/70R15C(8PR),225/70R15LT | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| JX493ZLQ4 | Jiangling Motors Group Co., Ltd. | 80kW | 2771ml |
