| Basic Information |
| Usage |
Refuse Collector |
| Fuel Type |
Natural gas |
| Emission Standard |
GB17691-2005 national Ⅴ emission standards, GB11340- 2005,GB18285-2005 |
| Length |
8347,8350,8450,8530,8675,8825mm |
| Width |
2500,2550mm |
| Height |
3430mm |
| Curb Weight |
12170kg |
| Gross Weight |
25000kg |
| Seats |
2,3 |
| Max Speed |
90km/h |
| Chassis |
| Chassis Model |
ND1250BG5J6Z03 |
| Front/Rear Overhang |
1410/1687,1410/1690,1410/1790,1410/1870,1435/1690,1435/1840mm |
| Number of Leaf Springs |
10/13,13/13 |
| Number of Axles |
3 |
| Wheelbase |
3800+1450,4100+1450mm |
| Axle Load |
7000/18000(two axles)kg |
| Front Wheel Track |
1995,2045,2004mm |
| Rear Wheel Track |
1800/1800,1872/1872,1878/1878mm |
| Approaching/Departuring Angle |
26/28,17/28° |
| Tire |
| Number of Tires |
10 |
| Tire |
12.00-20 18PR,12.00R20 16PR |
| Engine |
| Model |
WP10NG336E50,WP12NG350E50,WP12NG380E51,WP10NG336E51 |
| Power |
247,257,280,247kW |
| Brand |
Weichai West Port New Energy Power Co., Ltd.;Weichai West Port New Energy Power Co., Ltd.;Weichai West Port New Energy Power Co., Ltd.;Weichai West Port New Energy Power Co., Ltd.; |
| Displacement |
9726,11596,11596,9726ml |
