| Basic Information |
| Usage |
Refuse Collector |
| Fuel Type |
Diesel |
| Emission Standard |
GB17691-2005 national Ⅴ emission standards, GB3847-2005 |
| Length |
8705,8945,8535,8835,9185,8385mm |
| Width |
2550mm |
| Height |
3484mm |
| Curb Weight |
12500kg |
| Gross Weight |
25000kg |
| Seats |
2 |
| Max Speed |
80km/h |
| Chassis |
| Chassis Model |
ND3250BD5J7Z11 |
| Front/Rear Overhang |
1515/1940,1515/1880,1515/1770,1515/1990,1515/1930,1515/1820,1515/1670mm |
| Number of Leaf Springs |
10/12,4/5 |
| Number of Axles |
3 |
| Wheelbase |
3800+1450,4100+1450,4400+1450,3850+1350,4150+1350mm |
| Axle Load |
7000/18000(two axles)kg |
| Front Wheel Track |
2004mm |
| Rear Wheel Track |
1874/1874mm |
| Approaching/Departuring Angle |
17/36° |
| Tire |
| Number of Tires |
10 |
| Tire |
12.00R20 16PR,11.00R20 18PR,12R22.5 18PR |
| Engine |
| Model |
WP12.430E50,WP10H375E50 |
| Power |
316,276kW |
| Brand |
Weichai Holding Group Co., Ltd.; Weichai Holding Group Co., Ltd. |
| Displacement |
11596,9500ml |
