| Basic Information |
| Usage |
Refuse Collector |
| Fuel Type |
Diesel |
| Emission Standard |
GB3847-2005,GB17691-2018 national Ⅵ emission standards |
| Length |
8385,8525,8535,8815,8825,8935mm |
| Width |
2550mm |
| Height |
3484mm |
| Curb Weight |
12500kg |
| Gross Weight |
25000kg |
| Seats |
2 |
| Max Speed |
80km/h |
| Chassis |
| Chassis Model |
ND3250BD6J7Z03 |
| Front/Rear Overhang |
1515/1670,1515/1800,1515/1810,1515/1820,1515/1920mm |
| Number of Leaf Springs |
4/5,10/12 |
| Number of Axles |
3 |
| Wheelbase |
3850+1350,4150+1350,4100+1450,4400+1450,3550+1350mm |
| Axle Load |
7000/18000(two axles)kg |
| Front Wheel Track |
2004mm |
| Rear Wheel Track |
1874/1874mm |
| Approaching/Departuring Angle |
17/21,17/23,17/25° |
| Tire |
| Number of Tires |
10 |
| Tire |
12.00R20 16PR,11.00R20 18PR,12R22.5 18PR |
| Engine |
| Model |
WP10H350E62,WP10H375E62 |
| Power |
257,276kW |
| Brand |
Weichai Holding Group Co., Ltd.; Weichai Holding Group Co., Ltd. |
| Displacement |
9500,9500ml |
