| Basic Information | |||
| Usage | Refuse Collector | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 8575,8825,8375,8905 mm | ||
| Width | 2550mm | ||
| Height | 3430 mm | ||
| Curb Weight | 12260kg | ||
| Gross Weight | 25000kg | ||
| Seats | 2 | ||
| Max Speed | 80km/h | ||
| Chassis | |||
| Chassis Model | ND3250BD5J6Z05 | ||
| Front/Rear Overhang | 1435/1890,1435/1840,1435/1690,1435/1920 mm | ||
| Number of Leaf Springs | 10/13 | ||
| Number of Axles | 3800+1450,4100+1450,4450+1450,4750+1450 | ||
| Wheelbase | 3800+1450,4100+1450,4450+1450,4750+1450 mm | ||
| Axle Load | 7000/18000(two axles)kg | ||
| Front Wheel Track | 2004mm | ||
| Rear Wheel Track | 1878/1878,1904/1904 mm | ||
| Approaching/Departuring Angle | 17/25° | ||
| Tire | |||
| Number of Tires | 10 | ||
| Tire | 11.00R20 18PR,12.00R20 16PR,12R22.5 18PR,295/80R22.5 18PR,315/80R22.5 18PR/315/80R22.5 16PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| WP10.350E53 | Weichai Holding Group Co., Ltd. | 257，276kW | 9726，11596ml |
| WP12.375E50 | Weichai Holding Group Co., Ltd. | ||
