| Basic Information |
| Usage |
Refuse Collector |
| Fuel Type |
Diesel |
| Emission Standard |
GB17691-2005 national Ⅴ emission standards, GB3847-2005 |
| Length |
8795,8895,9585,10035mm |
| Width |
2550mm |
| Height |
3484mm |
| Curb Weight |
15500kg |
| Gross Weight |
31000kg |
| Seats |
2 |
| Max Speed |
80km/h |
| Chassis |
| Chassis Model |
ND3310DD5J7Z06 |
| Front/Rear Overhang |
1515/1380,1515/1430,1515/1480,1515/1530,1515/1620,1515/1770mm |
| Number of Leaf Springs |
4/4/5,10/10/12,4/4/12 |
| Number of Axles |
4 |
| Wheelbase |
1950+3150+1350,1950+3450+1350,1950+3750+1350,1950+2550+1350,1950+2850+1350,1950+2500+1450mm |
| Axle Load |
6500/6500/18000(two axles)kg |
| Front Wheel Track |
2004/2004mm |
| Rear Wheel Track |
1874/1874mm |
| Approaching/Departuring Angle |
17/36° |
| Tire |
| Number of Tires |
12 |
| Tire |
12.00R20 18PR,11.00R20 18PR,12R22.5 18PR |
| Engine |
| Model |
WP12.430E50,WP10H375E50,WP10H350E50 |
| Power |
316,276,257kW |
| Brand |
Weichai Holding Group Co., Ltd.;Weichai Holding Group Co., Ltd.; Weichai Holding Group Co., Ltd. |
| Displacement |
11596,9500,9500ml |
