| Basic Information | |||
| Usage | Refuse Collector | ||
| Fuel Type | Natural gas | ||
| Emission Standard | GB18285-2005,GB17691-2018 national Ⅵ emission standards | ||
| Length | 9700,9835,10085,10285,10435mm | ||
| Width | 2550mm | ||
| Height | 3484mm | ||
| Curb Weight | 15500kg | ||
| Gross Weight | 31000kg | ||
| Seats | 2 | ||
| Max Speed | 80km/h | ||
| Chassis | |||
| Chassis Model | ND3310DG6J7Z03 | ||
| Front/Rear Overhang | 1515/1385,1515/1435,1515/1520,1515/1570,1515/1720,1515/1770,1515/1820,1515/1870mm | ||
| Number of Leaf Springs | 4/4/5,10/10/12 | ||
| Number of Axles | 4 | ||
| Wheelbase | 1950+3450+1350,1950+3750+1350,1950+3400+1450mm | ||
| Axle Load | 6500/6500/18000( two axles)kg | ||
| Front Wheel Track | 2004/2004mm | ||
| Rear Wheel Track | 1874/1874mm | ||
| Approaching/Departuring Angle | 17/30° | ||
| Tire | |||
| Number of Tires | 12 | ||
| Tire | 12.00R20 18PR,11.00R20 18PR,12R22.5 18PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| WP10HNG350E60 | Weichai West Port New Energy Power Co., Ltd. | 257kW | 9500ml |
| WP13NG430E61 | Weichai West Port New Energy Power Co., Ltd. | 316kW | 12540ml |
