| Basic Information | |||
| Usage | Engineering Vehicle | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards | ||
| Length | 9600mm | ||
| Width | 2550mm | ||
| Height | 3960mm | ||
| Curb Weight | 13000kg | ||
| Gross Weight | 31000kg | ||
| Seats | 2 | ||
| Max Speed | 80km/h | ||
| Chassis | |||
| Chassis Model | ND1310DD5J6Z06 | ||
| Front/Rear Overhang | 1435/1965mm | ||
| Number of Leaf Springs | 4/4/5 | ||
| Number of Axles | 4 | ||
| Wheelbase | 1950+2900+1350mm | ||
| Axle Load | 6500/6500/18000(two axles)kg | ||
| Front Wheel Track | 2004/2004mm | ||
| Rear Wheel Track | 1874/1874mm | ||
| Approaching/Departuring Angle | 17/22° | ||
| Tire | |||
| Number of Tires | 12 | ||
| Tire | 12R22.5 18PR,11.00R20 18PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| WP8.340E51 | Weichai Holding Group Co., Ltd. | 250kW | 7800ml |
| J08E-YA | Shanghai Hino Engine Co., Ltd. | 224kW | 7684ml |
