| Basic Information |
| Usage |
Engineering Vehicle |
| Fuel Type |
Natural gas |
| Emission Standard |
GB 11340-2005,GB17691-2005 national Ⅴ emission standards, GB18285-2005 |
| Length |
10575,11075mm |
| Width |
2500,2550mm |
| Height |
3990mm |
| Curb Weight |
16025kg |
| Gross Weight |
31000kg |
| Seats |
2,3 |
| Max Speed |
90km/h |
| Chassis |
| Chassis Model |
ND1310DG5J6Z02 |
| Front/Rear Overhang |
1435/2640,1435/2840mm |
| Number of Leaf Springs |
12/12/13 |
| Number of Axles |
4 |
| Wheelbase |
1950+3100+1450,1950+3400+1450mm |
| Axle Load |
6500/6500/18000(two axles)kg |
| Front Wheel Track |
2045/2045mm |
| Rear Wheel Track |
1872/1872mm |
| Approaching/Departuring Angle |
26/15° |
| Tire |
| Number of Tires |
12 |
| Tire |
11.00-20 18PR,11.00R20 18PR,12.00-20 16PR,12.00R20 16PR |
| Engine |
| Model |
WP10NG336E50,WP12NG330E50,WP12NG350E50,WP12NG380E50,YC6MK340N-50,YC6MK375N-50 |
| Power |
247,243,257,280,250,276kW |
| Brand |
Weichai West Port New Energy Power Co., Ltd.; Weichai West Port New Energy Power Co., Ltd.; Weichai West Port New Energy Power Co., Ltd.; Weichai West Port New Energy Power Co., Ltd.; Guangxi YC Diesel Co., Ltd.; Guangxi YC Diesel Co., Ltd. |
| Displacement |
9726,11596,11596,11596,10338,10338ml |
