| Basic Information | |||
| Usage | Delivery Vehicle | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB3847-2005,GB17691-2005 national Ⅳ emission standards | ||
| Length | 12000mm | ||
| Width | 2500mm | ||
| Height | 3900mm | ||
| Curb Weight | 11900kg | ||
| Gross Weight | 31000kg | ||
| Seats | 3,2 | ||
| Max Speed | 98km/h | ||
| Chassis | |||
| Chassis Model | ND13106D46J | ||
| Front/Rear Overhang | 1410/2940,1410/2890,1410/2640,1410/2590mm | ||
| Number of Leaf Springs | 9/9/10,3/3/4 | ||
| Number of Axles | 4 | ||
| Wheelbase | 1950+4350+1350,1950+4300+1450,1950+4650+1350,1950+4600+1450mm | ||
| Axle Load | 6500/6500/18000(two axles)kg | ||
| Front Wheel Track | 1940/1940mm | ||
| Rear Wheel Track | 1847/1847mm | ||
| Approaching/Departuring Angle | 24/11° | ||
| Tire | |||
| Number of Tires | 12 | ||
| Tire | 10.00-20 18PR,10.00R20 18PR,11.00-20 18PR,11.00R20 18PR,295/80R22.5 18PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| WP7.270E40 | Weichai Holding Group Co., Ltd. | 199kW | 7140ml |
| WP7.300E40 | Weichai Holding Group Co., Ltd. | 220kW | 7140ml |
| WP10.270E40 | Weichai Holding Group Co., Ltd. | 199kW | 9726ml |
| WP10.300E40 | Weichai Holding Group Co., Ltd. | 221kW | 9726ml |
