| Basic Information | |||
| Usage | Engineering Vehicle | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 9430,10170mm | ||
| Width | 2500mm | ||
| Height | 3800mm | ||
| Curb Weight | 18800kg | ||
| Gross Weight | 34000kg | ||
| Seats | 2,3 | ||
| Max Speed | 90km/h | ||
| Chassis | |||
| Chassis Model | ND5340TTZZ02 | ||
| Front/Rear Overhang | 1515/2015,1515/2155mm | ||
| Number of Leaf Springs | 13/13 | ||
| Number of Axles | 3 | ||
| Wheelbase | 4450+1450,5050+1450mm | ||
| Axle Load | 8000/26000(two axles)kg | ||
| Front Wheel Track | 1995mm | ||
| Rear Wheel Track | 1800/1800mm | ||
| Approaching/Departuring Angle | 23/15,23/16° | ||
| Tire | |||
| Number of Tires | 10 | ||
| Tire | 12.00R20 20PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| WP12.375E50 | Weichai Holding Group Co., Ltd. | 276kW | 11596ml |
| WP12.430E50 | Weichai Holding Group Co., Ltd. | 316kW | 11596ml |
