| Basic Information | |||
| Usage | Vehicle for Special Work | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 10410mm | ||
| Width | 2500mm | ||
| Height | 3930mm | ||
| Curb Weight | 24870kg | ||
| Gross Weight | 25000kg | ||
| Seats | 2,3 | ||
| Max Speed | 90km/h | ||
| Chassis | |||
| Chassis Model | ND1250BD5J6Z00 | ||
| Front/Rear Overhang | 1435/2525mm | ||
| Number of Leaf Springs | 9/10,3/4,9/-,3/- | ||
| Number of Axles | 3 | ||
| Wheelbase | 4300+1350,4500+1350,4800+1350,5100+1350mm | ||
| Axle Load | 7000/18000(two axles)kg | ||
| Front Wheel Track | 1985mm | ||
| Rear Wheel Track | 1848/1848,1904/1904mm | ||
| Approaching/Departuring Angle | 15/12° | ||
| Tire | |||
| Number of Tires | 10 | ||
| Tire | 11.00R20 18PR,12.00R20 16PR,295/80R22.5 18PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| WP7.270E51 | Weichai Holding Group Co., Ltd. | 199kW | 7470ml |
| WP10.310E53 | Weichai Holding Group Co., Ltd. | 228kW | 9726ml |
