| Basic Information | |||
| Usage | Road-block Removal Truck | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB3847-2005,GB17691-2005 national Ⅳ emission standards | ||
| Length | 8000mm | ||
| Width | 2500mm | ||
| Height | 2885mm | ||
| Curb Weight | 5700kg | ||
| Gross Weight | 8490kg | ||
| Seats | 3 | ||
| Max Speed | 100km/h | ||
| Chassis | |||
| Chassis Model | DFL1080B7 | ||
| Front/Rear Overhang | 1365/2135mm | ||
| Number of Leaf Springs | 8/9+7 | ||
| Number of Axles | 2 | ||
| Wheelbase | 4500,4200,4700mm | ||
| Axle Load | 3500/4990kg | ||
| Front Wheel Track | 1800mm | ||
| Rear Wheel Track | 1680,1800mm | ||
| Approaching/Departuring Angle | 16/10° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 8.25-16,8.25R16,235/75R17.5 14PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| EQH140-40 | Dongfeng Trucks Co., Ltd. | 103kW | 4752ml |
