| Basic Information | |||
| Usage | Snow Sweeper | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅳ emission standardds, GB3847-2005 | ||
| Length | 9800mm | ||
| Width | 2500mm | ||
| Height | 3800mm | ||
| Curb Weight | 18600kg | ||
| Gross Weight | 25000kg | ||
| Seats | 2 | ||
| Max Speed | 78km/h | ||
| Chassis | |||
| Chassis Model | ZZ3257N3847D1 | ||
| Front/Rear Overhang | 1750/2875mm | ||
| Number of Leaf Springs | 10/12 | ||
| Number of Axles | 3 | ||
| Wheelbase | 3825+1350mm | ||
| Axle Load | 7000/18000(two axles)kg | ||
| Front Wheel Track | 2022,2041mm | ||
| Rear Wheel Track | 1830/1830mm | ||
| Approaching/Departuring Angle | 12/13° | ||
| Tire | |||
| Number of Tires | 10 | ||
| Tire | 11.00-20,11.00R20,12.00-20 18PR,12.00R20 16PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| D10.34-40 | China National Heavy Duty Truck Group Co., Ltd. | 249kW | 9726ml |
| D10.38-40 | China National Heavy Duty Truck Group Co., Ltd. | 276kW | 9726ml |
| D12.34-40 | China National Heavy Duty Truck Group Co., Ltd. | 249kW | 11596ml |
| D12.38-40 | China National Heavy Duty Truck Group Co., Ltd. | 279kW | 11596ml |
