| Basic Information | |||
| Usage | Others | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 11980mm | ||
| Width | 2550mm | ||
| Height | 3990mm | ||
| Curb Weight | 23870kg | ||
| Gross Weight | 24000,21880kg | ||
| Seats | 2 | ||
| Max Speed | 95km/h | ||
| Chassis | |||
| Chassis Model | TGX26.480, second-class, German MAN Commercial Vehicle | ||
| Front/Rear Overhang | 1475/3255mm | ||
| Number of Leaf Springs | -/-/- | ||
| Number of Axles | 3 | ||
| Wheelbase | 5900+1350mm | ||
| Axle Load | 6500/10500/7000,5920/9570/6390kg | ||
| Front Wheel Track | 2048mm | ||
| Rear Wheel Track | 1804/1994mm | ||
| Approaching/Departuring Angle | 13/11° | ||
| Tire | |||
| Number of Tires | 8 | ||
| Tire | 315/70R22.5 18PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| D2676LF38 | German MAN Commercial Vehicle Co., Ltd. | 356kW | 12419ml |
