| Basic Information | |||
| Usage | Others | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 11995mm | ||
| Width | 2500mm | ||
| Height | 3980mm | ||
| Curb Weight | 21870kg | ||
| Gross Weight | 22000kg | ||
| Seats | 2 | ||
| Max Speed | 110km/h | ||
| Chassis | |||
| Chassis Model | Actros 2536E5, second-class, Daimler AG | ||
| Front/Rear Overhang | 1440/3205mm | ||
| Number of Leaf Springs | 2/-/-,3/-/- | ||
| Number of Axles | 3 | ||
| Wheelbase | 6000+1350mm | ||
| Axle Load | 6100/9800/6100kg | ||
| Front Wheel Track | 2036mm | ||
| Rear Wheel Track | 1804/1959mm | ||
| Approaching/Departuring Angle | 6/11° | ||
| Tire | |||
| Number of Tires | 8 | ||
| Tire | 295/80 R22.5 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| OM501LA.V/2 | Daimler AG | 270kW | 11946ml |
