| Basic Information | |||
| Usage | Others | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 8200mm | ||
| Width | 2550mm | ||
| Height | 3800mm | ||
| Curb Weight | 12670kg | ||
| Gross Weight | 12800kg | ||
| Seats | 2 | ||
| Max Speed | 95km/h | ||
| Chassis | |||
| Chassis Model | ZZ5176XXYM561GE1 | ||
| Front/Rear Overhang | 1430/2270mm | ||
| Number of Leaf Springs | 3/-,3/2+-,-/- | ||
| Number of Axles | 2 | ||
| Wheelbase | 4500,5200,5600,5800,3800,3600mm | ||
| Axle Load | 4500/8300kg | ||
| Front Wheel Track | 2015,2035mm | ||
| Rear Wheel Track | 1816mm | ||
| Approaching/Departuring Angle | 16/12° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 275/80R22.5,295/80R22.5 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| MC07.28-50 | China National Heavy Duty Truck Group Co., Ltd. | 206kW | 6870ml |
| MC07.31-50 | China National Heavy Duty Truck Group Co., Ltd. | 228kW | 6870ml |
