| Basic Information | |||
| Usage | Others | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅳ emission standards, GB3847-2005 | ||
| Length | 11995mm | ||
| Width | 2500mm | ||
| Height | 3980mm | ||
| Curb Weight | 21520kg | ||
| Gross Weight | 21650kg | ||
| Seats | 2 | ||
| Max Speed | 110km/h | ||
| Chassis | |||
| Chassis Model | TGX26.360, second-class, German MAN Commercial Vehicle Co., Ltd. | ||
| Front/Rear Overhang | 1475/3270mm | ||
| Number of Leaf Springs | -/-/- | ||
| Number of Axles | 3 | ||
| Wheelbase | 5900+1350mm | ||
| Axle Load | 6500/8650/6500kg | ||
| Front Wheel Track | 2048mm | ||
| Rear Wheel Track | 1804/1994mm | ||
| Approaching/Departuring Angle | 13/12° | ||
| Tire | |||
| Number of Tires | 8 | ||
| Tire | 315/70R22.5 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| D2066LF42 | German MAN Commercial Vehicle Co., Ltd. | 268kW | 10518ml |
