| Basic Information | |||
| Usage | Vehicle for Special Work | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 7650mm | ||
| Width | 2175mm | ||
| Height | 3350,3200mm | ||
| Curb Weight | 5870kg | ||
| Gross Weight | 6000,5630kg | ||
| Seats | 2 | ||
| Max Speed | 90km/h | ||
| Chassis | |||
| Chassis Model | 70C17H V, IVECO Co., Ltd. Suzzara Plant | ||
| Front/Rear Overhang | 1008/2542mm | ||
| Number of Leaf Springs | 0/0 | ||
| Number of Axles | 2 | ||
| Wheelbase | 4100mm | ||
| Axle Load | 1950/4050,1820/3810kg | ||
| Front Wheel Track | 1725mm | ||
| Rear Wheel Track | 1660mm | ||
| Approaching/Departuring Angle | 19.61/6.53° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 225/75R16C | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| F1CFL411F*A | FPT INDUSTRIAL S.p.A. | 126kW | 2998ml |
