| Basic Information | |||
| Usage | Vehicle for Special Work | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 6210mm | ||
| Width | 2150mm | ||
| Height | 3620mm | ||
| Curb Weight | 5370kg | ||
| Gross Weight | 5500kg | ||
| Seats | 2 | ||
| Max Speed | 90km/h | ||
| Chassis | |||
| Chassis Model | 55C17HW, second-class, IVECO Co., Ltd. Suzzara Plant | ||
| Front/Rear Overhang | 900/1910mm | ||
| Number of Leaf Springs | 3/4 | ||
| Number of Axles | 2 | ||
| Wheelbase | 3400mm | ||
| Axle Load | 2400/3100kg | ||
| Front Wheel Track | 1670mm | ||
| Rear Wheel Track | 1670mm | ||
| Approaching/Departuring Angle | 46/21° | ||
| Tire | |||
| Number of Tires | 4 | ||
| Tire | 255/100R16 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| F1CFL411F*A | FPT INDUSTRIAL S.p.A. | 126kW | 2998ml |
