| Basic Information | |||
| Usage | Delivery Vehicle | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 6890mm | ||
| Width | 2135mm | ||
| Height | 3000,3270,3170mm | ||
| Curb Weight | 4440kg | ||
| Gross Weight | 9995kg | ||
| Seats | 3 | ||
| Max Speed | 80km/h | ||
| Chassis | |||
| Chassis Model | BJ1109VEJEA-FB | ||
| Front/Rear Overhang | 1120/1970mm | ||
| Number of Leaf Springs | 9/11+7,3/7+6,3/8+6,3/4+2,3/5+2 | ||
| Number of Axles | 2 | ||
| Wheelbase | 3800mm | ||
| Axle Load | 3600/6395kg | ||
| Front Wheel Track | 1665,1730,1590mm | ||
| Rear Wheel Track | 1630,1680,1800,1485mm | ||
| Approaching/Departuring Angle | 19/16° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 8.25-16,8.25R16,8.25R20 12PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| ISF3.8s5154 | Beijing Foton Cummins Engine Corporation | 115kW | 3760ml |
