| Basic Information | |||
| Usage | Delivery Vehicle | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 8880mm | ||
| Width | 2550mm | ||
| Height | 3475mm | ||
| Curb Weight | 6020kg | ||
| Gross Weight | 15900kg | ||
| Seats | 3 | ||
| Max Speed | 80km/h | ||
| Chassis | |||
| Chassis Model | BJ1169VKPEK-FG | ||
| Front/Rear Overhang | 1250/2430mm | ||
| Number of Leaf Springs | 8/10+10 | ||
| Number of Axles | 2 | ||
| Wheelbase | 4700,5200mm | ||
| Axle Load | 5600/10300kg | ||
| Front Wheel Track | 1830mm | ||
| Rear Wheel Track | 1800mm | ||
| Approaching/Departuring Angle | 21/11° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 9.00R20 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| ISF3.8s5168 | Beijing Foton Cummins Engine Corporation | 125kW | 3760ml |
| ISF3.8s5154 | Beijing Foton Cummins Engine Corporation | 115kW | 3760ml |
