| Basic Information | |||
| Usage | Vehicle for Special Work | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005( national Ⅳ emission standards),GB3847-2005 | ||
| Length | 9500mm | ||
| Width | 2500mm | ||
| Height | 3700mm | ||
| Curb Weight | 24870kg | ||
| Gross Weight | 25000kg | ||
| Seats | 2 | ||
| Max Speed | 90km/h | ||
| Chassis | |||
| Chassis Model | YC5330FS1ER4 | ||
| Front/Rear Overhang | 1410/2180mm | ||
| Number of Leaf Springs | 10/13,10/14 | ||
| Number of Axles | 3 | ||
| Wheelbase | 4500+1410mm | ||
| Axle Load | 7000/18000(two axles)kg | ||
| Front Wheel Track | 2060mm | ||
| Rear Wheel Track | 1855/1855mm | ||
| Approaching/Departuring Angle | 17/14° | ||
| Tire | |||
| Number of Tires | 10 | ||
| Tire | 295/80R22.5 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| E13C UN | HINO MOTORS | 304.2kW | 12913ml |
