| Basic Information | |||
| Usage | Vehicle for Special Work | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB3847-2005,GB17691-2005 national Ⅳ emission standards | ||
| Length | 9280mm | ||
| Width | 2500mm | ||
| Height | 3950mm | ||
| Curb Weight | 12300kg | ||
| Gross Weight | 12495kg | ||
| Seats | 3 | ||
| Max Speed | 100km/h | ||
| Chassis | |||
| Chassis Model | DFL1120B13 | ||
| Front/Rear Overhang | 1430/2850mm | ||
| Number of Leaf Springs | 7/9+6,8/10+8 | ||
| Number of Axles | 2 | ||
| Wheelbase | 4700,5000mm | ||
| Axle Load | 4400/8095kg | ||
| Front Wheel Track | 1880,1924mm | ||
| Rear Wheel Track | 1800mm | ||
| Approaching/Departuring Angle | 20/15° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 9.00-20,9.00R20,255/70R22.5 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| ISDe180 40 | Dongfeng Cummins Engine Co., Ltd. | 132kW | 4500ml |
| ISDe160 40 | Dongfeng Cummins Engine Co., Ltd. | 118kW | 4500ml |
| ISDe185 40 | Dongfeng Cummins Engine Co., Ltd. | 136kW | 6700ml |
| EQH160-40 | Dongfeng Trucks | 118kW | 4752ml |
| EQH180-40 | Dongfeng Trucks | 132kW | 4752ml |
| ISB180 40 | Dongfeng Cummins Engine Co., Ltd. | 132kW | 5900ml |
